| Place of Origin: | Langfang City, Hebei Province, China |
| Brand Name: | XINYUAN |
| Certification: | ISO9001 quality management system certification |
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Regular paper packaging. Depending on the model, the packaging will vary. |
| Delivery Time: | 3 days |
| Payment Terms: | T/T |
| Supply Ability: | 10,000 units per month |
| Dimensions (W×H×D) (mm): | 595×595×21 | Rated Air Volume (m3/h): | 1700 |
|---|---|---|---|
| Filter Area(m2): | 0．64 | Dust Holding Capacity (g): | 115 |
| Initial Resistance (Pa): | 45 | Final Resistance （Pa）: | 100-200 |
| High Light: | G3 Pleated Panel Filters,G3 primary air filter,45Pa Pleated Panel Filters |
||
Stainless Steel Mesh Folding Panel Filter
Product Description:
The flame-retardant filter is folded into a polypropylene flame-retardant fiber material, and fixed by a stainless steel wire mesh on both sides. It has good high temperature resistance and fire resistance. Suitable for high temperature environment.
Product parameter:
|
Dimensions (W×H×D) (mm) |
Rated air volume (m3/h) |
Filter area(m2) |
Dust holding capacity (g) |
Initial resistance (Pa) |
Final resistance (Pa) |
Filtration efficiency(0.3μm) |
|
595×595×21 |
1700 |
0．64 |
115 |
45 |
100-200 |
G1-G4 |
|
595×495×21 |
1400 |
0．53 |
95 |
45 |
100-200 |
|
|
295×295×21 |
400 |
0．16 |
25 |
45 |
100-200 |
|
|
595×595×46 |
2500 |
0．95 |
170 |
45 |
100-200 |
|
|
595×495×46 |
2100 |
0．78 |
140 |
45 |
100-200 |
|
|
295×595×46 |
1200 |
0．46 |
80 |
45 |
100-200 |
|
|
295×495×46 |
1000 |
0．38 |
65 |
45 |
100-200 |
|
|
295×295×46 |
600 |
0．24 |
40 |
45 |
100-200 |
|
|
Minimum order quantity: 100 pcs. Supply capacity: 10,000 pcs/month. Delivery time: 3 days |
||||||
Item Features:
Aluminum alloy profile frame, polypropylene material connector, firm structure, compact, beautiful appearance.
FAQ:
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 50% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: Are you a trading company or manufacturer?
A: We are professional manufacturer with factory in China.
Q: What kinds of filter do you produce?
A: It covers widely for air filter,oil filter,fuel filter for trucks, construction machinery, power plant equipment,compressor-turbine unit etc.
